GE49-HDMI 2x4 HDMI Switch/Splitter 2K and 4K 1080P 3D

0 out of 5.0

(0 บทวิจารณ์)

ยังไม่มีการรีวิวสำหรับสินค้านี้

คำอธิบาย

2 x 4 HDMI switch splitter can connect 2 HD signal sources to 4 HD display terminals. It can easily split the 2 HD signals generated by the 2 HD signal sources to 4 HD displayers or projectors. In addition, when connected to a HDMI output cable, it can amplify the HDMI signal. The 2 signal sources can be switched freely. The HDMI splitter can support all HD multichannel audio formats including 720p, 1080i, 1080p,2160p. It also supports the 3.5 mm headphones audio output and SPDIF audio output.Specifications:
HDMI version: HDMI 1.4b
HDMI resolution: up to 3840*2160/30Hz
Support video colour format:8/10/12 bit deep colour
Support audio format: DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD
Max bandwidth: 300MHz
Max baud rate: 3Gbps
Input cable distance: (1080p resolution)≤15m,(4K resolution)≤8m AWG26 HDMI standard cable
Output cable distance: (1080p resolution)≤15m,(4K resolution)≤8m AWG26 HDMI standard cable
Max working current:1000mA
Power adapter format: Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/2AOperating and Connecting:
1.Connect HDMI source device and HDMI Switch/Splitter input with two cables.
2.Connect displayer and HDMI Switch/Splitter output with four cables.
3.Connect power adapter to the HDMI Switch/Splitter.

With built-in automatical adjusting amplifier, it can regenerate the HDMI signal before sending it to the outputs by a longer HDMI cable
When HDMI cable connects with HDMI output , the 2x4 switch/splitter can amplify the HDMI singal; supporting highest video resolution 1080p/60Hz, HDMI1.4a, 3D .4KX2K
Switches between two input source devices and send the signal simultaneously to four displays.(the 4 display show the same piture at the same time)
This Hdmi selector support single high definition display for multiple sources, such as DVD Players and Stellite Receivers, Digital Projectors, A/V Receivers, Set Top Boxes
HDMI switcher - Plug and Play.This Hdmi splitter switch Support 3d-1080p,hdmi1.3v -Hdcp 1.2. You Can Connect 2 Different Input Source to four Display Such As connect Dvd, Camera, Cellphone,sky-stb,xbox360 roku to one tv /projector ,roku At the Same Time .

ข้อมูลเฉพาะของ HDMI 2x4 HDMI Switch/Splitter 2K and 4K 1080P 3D

ภายในกล่องสินค้า

1X HDMI 2x4 HDMI Switch/Splitter 2K and 4K 1080P 3D
